Icom IC-F2020 [3/20] Table of contents

TABLE OF CONTENTS

IMPORTANT ........................................................................ i

EXPLICIT DEFINITIONS ..................................................... i

CAUTIONS ........................................................................... i

TABLE OF CONTENTS ...................................................... ii

1 PANEL DESCRIPTION ............................................. 1–5

■ Front panel ............................................................................ 1

■ Programmable function keys ................................................ 2

■ Function display .................................................................... 5

2 OPERATION ............................................................. 6–8

■ Turning power ON ................................................................. 6

■ Channel selection ................................................................. 6

■ Receiving and transmitting ................................................... 7

D Transmitting notes........................................................... 7

D DTMF transmission ......................................................... 8

3 CONNECTION AND INSTALLATION .................... 9–12

■ Rear panel and connection ................................................... 9

■ Unpacking ........................................................................... 10

■ Mounting ............................................................................. 11

■ Separation .......................................................................... 11

■ Optional UT-105 installation ................................................ 12

4 OPTIONAL SmarTrunk II™ OPERATION ........... 13–15

■ SmarTrunk II™ and conventional modes ............................ 13

■ SmarTrunk II™ operation .................................................... 13

5 OPTIONS .................................................................... 16

DO NOT use or place the transceiver in areas with tem-

peratures below –30°C (–22°F) or above +60°C (+140°F) or,

in areas subject to direct sunlight, such as the dashboard.

AVOIDoperate the transceiver without running the vehicle’s

engine. The vehicle’s battery will quickly run out if the trans-

ceiver is in transmission while the vehicle’s engine OFF.

AVOID placing the transceiver in excessively dusty envi-

ronments.

AVOID placing the transceiver against walls. This will ob-

struct heat dissipation.

AVOID the use of chemical agents such as benzine or al-

cohol when cleaning, as they damage the transceiver sur-

faces.

BE CAREFUL! The transceiver will become hot when

operating continuously for long periods.

For U.S.A. only

CAUTION: Changes or modiﬁcations to this transceiver,

not expressly approved by Icom Inc., could void your authority

to operate this transceiver under FCC regulations.
