Icom IC-F2020 [4/20] Panel description
![Icom IC-F2020 [4/20] Panel description](/views2/1074587/page4/bg4.png)
P0 P1 P2 P3
VOLUME CONTROL
MICROPHONE
CONNECTOR
FUNCTION DISPLAY SPEAKER
POWER SWITCHPROGRAMMABLE
FUNCTION KEYS
PROGRAMMABLE
FUNCTION KEYS
PANEL DESCRIPTION
1
1
■Front panel
