■Programmable function keys
The following functions can be assigned to programmable
function keys. Assigned function names can be affixed to the
LCD using supplied stickers.
CHANNEL UP AND DOWN KEYS
• Select an operating channel
• Select a bank after pushing the [
BANK S
] key.
• Select a DTMF channel after pushing the [
DTMF
]
key.
• Select a scan group after pushing and holding the
[
SCAN
] key.
BANK UP AND DOWN KEYS
Select a bank (a group of 16 (or multiples of) chan-
nels).
• This function may be available for the optional 160 chan-
nel type only.
• When the optional UT-105 is installed, push one or more
times to select a channel bank for conventional channels
or SmarTrunk II™ channels.
1
PANEL DESCRIPTION
2
VOLUME CONTROL
Adjusts the audio output level.
•Minimum audio level (when setting control at maximum
counterclockwise) is pre-programmed.
POWER SWITCH
Turns the power ON and OFF.
•The following functions are available at power ON as op-
tions:
• Automatic scan start
• Password prompt
MICROPHONE CONNECTOR
Connects the supplied microphone or optional DTMF micro-
phone for SmarTrunk II™ operation here.
NEVER connect other microphones. The pin assignments
may be different and the transceiver may be damaged.
MICROPHONE
The supplied microphone has a PTT switch and a hanger
hook.
•The following functions are available when the microphone is
hung on or released form the microphone hanger:
• Automatic scan start when hung.
• Automatic priority channel selection when released.
• Turns OFF and ON the monitor function when hung or released
respectively.
CH UP
CH DN
BK UP
BK DN
