Icom IC-M34 [19/36] I monitor function
![Icom IC-M34 [19/36] I monitor function](/views2/1074620/page19/bg13.png)
13
4
BASIC OPERATION
4
■ Monitor function
The monitor function opens the squelch. See p. 5 for details
of the monitor key action.
➥ The monitor function activates while pushing and holding
[MONI] (SQL).
•“ ” blinks and audio is emitted.
■
AquaQuake water draining function
The IC-M34 uses a new technology to clear water away from
the speaker grill: AquaQuake. AquaQuake helps drain water
away from the speaker housing (water that might otherwise
muffle the sound coming from the speaker). The IC-M34
emits a vibrating beep when this function is being used.
➥ Push and hold both [SCAN] and [H/L].
• A low beep tone sounds for 9 sec. to drain water, regardless of
volume level setting.
• The transceiver does not perform key operations while the
AquaQuake function is activated. The AquaQuake function can not
be activated when an optional speaker-microphone is connected.
Push and hold
Blinks while the monitor function is used.
