Icom IC-M34 [24/36] I set mode items
![Icom IC-M34 [24/36] I set mode items](/views2/1074620/page24/bg18.png)
18
7 SET MODE
■ Set mode items
D Beep tone function “bP”
Select the key touch beep sound from ON or US, or turn sound
OFF.
• US : The preset beeps (e.g. do, re, mi) sound
• ON : A fixed beep sounds (default)
• OFF: Silent operation
D Weather alert function “AL”
A NOAA broadcast station transmits a weather alert tone be-
fore any important weather announcements. When the
weather alert function is turned ON and the transceiver detect
the alert, “WX ALT” indicator blinks and a beep tone sounds.
The blinking stops when the transceiver is operated.
The currently selected weather channel is checked when the
power save function is turned ON or while scanning.
•“ALT” appears when the function is set ON.
D Priority scan function “Pr”
The transceiver has 2 scan types— normal (OFF) and priority
(ON) scans. Normal scan searches all TAG channels in the
selected channel group. Priority scan searches all TAG chan-
nels in sequence while monitoring Channel 16.
D Scan resume timer “St”
The scan resume timer can be set as a pause (OFF) or timer
scan (ON). When OFF is selected, the scan pauses until a
received signal disappears. When ON is selected, the scan
pauses for 5 sec. after receiving a signal and then resumes
even if the signal is being received.
Push
Scan resume timer OFF
(default)
Scan resume timer ON
Push
Normal scan (default) Priority scan
Push
Weather alert function
OFF (default)
Weather alert function
ON
Push
Beep tone ON (default) Beep tone OFF
