Icom IC-M34 [32/36] Troubleshooting
![Icom IC-M34 [32/36] Troubleshooting](/views2/1074620/page32/bg20.png)
26
TROUBLESHOOTING
10
PROBLEM POSSIBLE CAUSE SOLUTION REF.
No sound from speaker. • Squelch level is too high.
• Volume level is too low.
• Speaker has been exposed to water.
p. 12
p. 11
p. 13
• Set squelch to the threshold point.
• Push [
YY
]/[
ZZ
] after pushing [VOL] to set a
suitable level.
• Drain water from the speaker.
The transceiver does
not turn ON.
• The battery is exhausted.
• The battery pack is not attached correctly.
p. 23
p. 3
• Recharge the battery pack.
• Attach the battery pack correctly.
Transmitting is impossi-
ble, or high power can
not be selected.
• Some channels are for low power or re-
ceive only.
• The battery is exhausted.
• The battery over charged.
• The output power is set to low.
pgs. 8,
9, 27
p. 23
—
p. 10
• Change channels.
• Recharge the battery pack.
• Verify the battery voltage is correct.
• Push [H/L] to select high power.
The displayed channel
cannot be changed.
• Lock function is activated. • Push and hold [LOCK] (H/L) for 1 sec. to
cancel the function.
p. 12
Scan does not start. •“TAG” channels are not programmed. • Set the desired channels as “TAG” channels. p. 15
No beeps. • Beep tone function is turned OFF. • Set the beep tone to ON (Fix Beep/User
Beep) in set mode.
p. 18
Battery voltage error • The connected battery pack’s voltage is
more than 11 V.
• Verify the battery voltage is correct. —
