FOREWORD
Thank you for purchasing this Icom radio. The IC-M34
VHF MA
-
RINE TRANSCEIVER
is designed and built with Icom’s state of the
art technology and craftsmanship. With proper care this radio
should provide you with years of trouble-free operation.
IMPORTANT
READ ALL INSTRUCTIONS carefully and com-
pletely before using the transceiver.
SAVE THIS INSTRUCTION MANUAL—This in-
struction manual contains important operating instructions for
the IC-M34.
EXPLICIT DEFINITIONS
FEATURES
☞ Submersible construction
Built tough to withstand the punishing marine environ-
ment, the IC-M34’s submersible construction meets IPX7
of the corresponding International Standard IEC 60529
(2001) while using BP-251 (option) or BP-252.
☞ Floating on water
The IC-M34 floats on fresh or salt
water even when the supplied acces-
sories are attached.
• When third-party battery pack, strap, an-
tenna, etc. is used, it may sink.
• The battery contacts may be prone to rust-
ing if the transceiver is kept floating in
fresh or salt water.
☞ Large, easy-to-read LCD
With dimensions of 16(H) × 32(W) mm;
5
⁄8(H) × 1
1
⁄4(W)
inch, the IC-M34’s function display is easy to read and
shows operating conditions at a glance. Backlighting and
contrast can be adjusted to suit your preferences.
☞ Simple operation
9 large buttons on the front panel provide user-friendly op-
eration. The independent volume and channel buttons are
located on the front panel for convenient one-hand opera-
tion.
DEFINITION
RWARNING
CAUTION
NOTE
Personal injury, fire hazard or electric shock
may occur.
If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.
Equipment damage may occur.
WORD
iii
