Icom IC-R2 [7/40] Panel description
![Icom IC-R2 [7/40] Panel description](/views2/1074698/page7/bg7.png)
3
2
PANEL DESCRIPTION
t VOLUME CONTROL SWITCHES [VOLY]/[VOLZ]
➥Push to adjust the audio level. (p. 10)
➥Push [FUNC] + either switch to start a scan. (p.16)
➥Push [FUNC] + either switch for 2 sec. to start a tone
scan. (p.23)
y VFO/MEMORY SWITCH [V/M (MW)]
➥Toggles between VFO and memory modes. (p. 6)
➥Enters set mode when pushed for 2 sec. (p. 25)
➥Push [FUNC] + [
(V/M)MW] to enter memory write mode.
(p. 12)
➥Push [FUNC] + [
(V/M)MW] for 1 sec. to write the operat-
ing frequency into the selected memory channel in VFO
mode. Keep pushing for 2 sec. or more to automatically
select the next memory channel, if desired. (p. 12)
➥Push [FUNC] + [
(V/M)MW] for 1 sec. to write the dis-
played frequency into the VFO in memory mode. (p. 13)
u POWER SWITCH [POWER]
Push for 2 sec. to toggle the receiver power ON and OFF.
i TUNING STEP/MEMORY SKIP SWITCH [TS (SKIP)]
➥Enters tuning step set mode. (p. 7)
➥Push [FUNC] + [
(TS)SKIP] to toggle the frequency skip
function ON or OFF in VFO mode. (p. 19)
➥Push [FUNC] + [
(TS)SKIP] for 2 sec. to program the dis-
played frequency as a skip frequency during full, band
or programmed scan. (p. 19)
➥Push [FUNC] + [
(TS)SKIP] to toggle the channel as skip,
program skip or non-skip channel in memory mode. (p.
18)
o MODE/LOCK SWITCH [MODE (LOCK)]
➥Selects the receive mode. (p. 11)
➥Push [FUNC] + [
(MODE)LOCK] to toggle the lock function
ON and OFF. (pgs. 8, 28)
!0 EXTERNAL SPEAKER JACK [SP]
Connects an optional earphone or headphone. The inter-
nal speaker will not function when any external equipment
is connected. (See p.35 for a list of available options.)
!1 TUNING DIAL [DIAL]
➥Rotate [DIAL] to set operating frequencies, memory
channels, set mode contents, etc. (p. 7)
➥While scanning, changes the scanning direction. (p. 16)
➥While pushing [SQL], sets the squelch level. (p. 10)
➥While pushing [FUNC], sets the operating frequency in
100 kHz, 1 MHz or 10 MHz steps in VFO mode.(pgs. 7,
26)
➥While pushing [FUNC], selects memory bank in mem-
ory mode. (p. 12)
➥While pushing [BAND], selects the operating band in
VFO mode. (p. 6)
