ENGLISH en
11
- Press the button (16); the LEDs indicate the
charge level. (15)
- (15)If one LED is flashing, the battery pack is
almost flat and must be recharged.
7.9 Removing or replacing the battery pack
Fig. A
To remove: Press the battery pack release (13)
button and pull the battery pack (14) upwards
.
To fit:Slide in the battery pack (14) until it engages.
8.1 Chip blower
Fig. A
Turn the button (8) to turn on (symbol ) or off.
8.2 Set the pendulum motion
Fig. A
Set the required pendulum motion using the adjust-
ment lever (7).
Position "0" = pendulum motion is switched off
. . .
Position "III" = maximum pendulum motion
Recommended settings:
Fig. G.
The best way to determine the ideal setting is
through a practical trial.
8.3 Set the maximum speed/stroke
Fig. A
Set the machine to maximum speed using the
setting wheel (12). This is also possible during oper-
ation.
Setting wheel position "A" = automatic start-up
system: during the sawing process, the speed auto-
matically increases to the maximum speed.
Recommended settings:
Fig. G.
The best way to determine the ideal setting is
through a practical trial.
8.4 Switching on/off, continuous operation
Fig. A
The machine must not be allowed to draw in
additional dust and shavings. When switching
the machine on and off, keep it away from dust
deposits. After switching off the machine, only place
it down when the motor has come to a standstill.
Avoid switching on the machine accidentally:
always switch it off when the battery pack is
removed from the machine.
In continuous operation, the machine
continues running if it is forced out of your
hands. Therefore always hold the machine with
both hands using the handle provided, stand
securely and concentrate.
Switching on: Push the slide switch (9) forward.
For continuous activation, now tilt downwards until
it engages.
Switching off: Press the rear end of the slide
switch (9) and release.
8.5 LED light
Fig. A
For working on dimly lit areas. The LED lights (4)
light up when the machine is switched on.
If the LED light is flashing, see chapter 10.
8.6 Note on use
Fig. E
Plunging You can plunge the jigsaw blade into
workpieces made from thin, soft materials without
needing to drill a hole beforehand. Only use short
saw blades. Only at 0° angle setting.
Set the adjustment lever (7) to the "0" position
(pendulum motion is deactivated). Position the
jigsaw with the front edge of the footplate (10) on the
workpiece. Hold the operating jigsaw firmly and
guide slowly downwards. Once the saw blade has
penetrated the workpiece, the pendulum motion
can be activated.
Clean the machine regularly. This includes
vacuum cleaning the ventilation louvres on the
motor.
(19) Clean the saw blade clamping fixture regularly
and thoroughly by applying a jet of compressed air.
If necessary, clean the openings behind the saw
blade support roller (18).
Apply a drop of oil to the saw blade support roller
(18) from time to time.
If necessary, adjust the clamping force of the clamp
lever (22)
(
Fig. D): Release the safety screw
(23) and turn the clamping force screw (24) (turning
the screw anti-clockwise increases the clamping
force). Tighten the safety screw (23).
The LED light (4) is flashing SLOWLY and the
machine has been switched off automatically.
The machine switches off if it is overloaded for an
extended period or if the saw blade is jammed.
Switch off the machine at the slide switch (9).
Switch it on again and continue to work as normal.
Avoid any additional overloading or jamming.
The LED (4) is flashing quickly and the machine
is not running. The restart protection is active. The
machine will not start if the battery pack is inserted
while the machine is on. Switch the machine off and
on again.
Only use original Metabo accessories
Fig. F.
Use only accessories which fulfil the requirements
and specifications listed in these operating instruc-
tions.
Fit accessories securely. Secure the machine if it is
operated in a bracket. Loss of control can cause
personal injury.
AChargers
B Battery pack
C Circular-cutting and parallel guide
8. Use
9. Cleaning, Maintenance
10. Troubleshooting
11. Accessories
