Metabo ClassicAir 255 [16/112] English

ENGLISH

Pressure vessel volume l 24

No. of air outlets 1

No. of cylinders 1

Driving torque Cylinder head bolt Nm 10

Motor speed min

-1

2850

Motor capacity kW 1.5

Supply voltage (50 Hz) V 230

Nominal current A 7.2

Fuse protection min. A 10 (time-lag)

Degree of protection IP 20

Max. overall cable length when using extension cables:

– at 3 x 1.0 mm

lead cross section

– at 3 x 1.5 mm

lead cross section

– at 3 x 2.5 mm

lead cross section

Oil grade (compressor pump) SAE 40 (SAE 20)

Required oil quantity (pump) l approx. 0.25

Dimensions: length x width x height mm 555 × 310 × 600

Weight kg 27

Sound pressure level L

in 1 m max. dB (A) 87 ± 3

Guaranteed sound power level L

dB (A) 94

All technical specifications apply to an ambient temperature of 20 °C.

*) The technical life of some components, the check valve sealing, for instance, is substantially decreased when the compressor

is used at high temperatures (max. storage/operating temperature and higher).

**) At temperatures below the min. storage/operating temperature there persists a danger of the condensate in the pressure ves-

sel freezing.
