Pagina 6
English
DESCRIPTION:
1. Cold water tank
2. Cup warmer
3. \
4. Steam/hot water lever switch
5. Filter holder retaining ring
6. Steam/hot water arm
7. Removable water drainage tray
8. Filter holder
9. Single cup filter
10. Two cup filter
11. On/off switch with LED (on the right side)
12. Indicator light on/off for steam/hot water
solenoid valve
13. Coffee/hot water/steam lever switch
14. Indicator light: machine on
15. Tamper
16. Measuring spoon
17. Manometer
18. Filter for pods
19. Removable water tank cover (on the back side)
20. Water level indicator
21. Indicator light coffee/steam ready
22. Pump lever switch
USER INSTRUCTIONS:
Starting of the machine:
1. Remove the machine from its packing and make sure all packing parts have been taken off (including the
protection bags).
2. Lay the machine on a flat and steady surface far away from hot places and from the water taps.
3. Remove the water tank cover (19) and take out the water tank (1) paying attention not to damage the water
tubes inside the tank.
4. Fill the tank (1) with cold water.
5. Replace the water tank back in the machine and check that the water tubes are not bent and that the filter is
well set on one of them; reposition the tank cover (19).
6. Plug in the machine in the mains. Make sure that the wall socket has the right voltage.
7. Place the filter holder (8) under the brewing group (5) and turn it from the left to the right. Leave it there so
that it can get warm and it gets ready for use.
8. Turn the machine on by pushing the on /off switch (11). The indicator light of the switch (11) and the indicator
light (14) come on to confirm the power supply.
9. Push up the steam/hot water lever switch (4): the indicator light (12) comes on.
10. Push up the pump lever switch (22) and position the lever switch (13) on hot water mode (middle).
11. Once water comes out of the steam/hot water nozzle (6), push down the pump switch (22) and the steam/hot
water lever switch (4). Position the lever switch (13) on coffee mode (down).
12. After completing all these operations, leave the machine on.
Preparing an espresso:
13. Check that the water tank (1) has been filled in with water by looking at the water level indicator (20).
14. Press the on/off switch (11): the indicator light of the switch (11) and the indicator light (14) will come on. Do
this operation only if the machine is off. If it’s on pass to the following point.
15. As soon as the indicator light (21) comes on, the machine is ready for use. Check the position of the switch
(13): make sure it is on coffee mode (down).
16. Fit the single cup filter (9) or the two cup filter (10) into the filter holder (8) that has been warmed up by
leaving it attached to the brewing group as described in point 7.
17. Fill the filter with ground coffee by means of the supplied measure spoon (16): 1+ ½ measuring spoonful (16)
= 1 coffee cup - 3 measuring spoonful (16) = 2 coffee cups. Every time you fill the filter with a spoonful of
coffee, press the coffee with the coffee press/tamper (15) before proceeding to fill it with the next spoonful
and make sure that there are no coffee rests on the filter border.
18. Insert the filter holder (8) in the brewing group ring (5), turn it from left to right with force, then put the cup
on the removable water drainage tray (7).
19. Push up the pump switch (22). The manometer (17) will show the reached pressure, between 8 and 14 bar.
20. Once you get the desired quantity of coffee, push down the switch (22) again.
21. Remove the filter holder (8) and throw away the coffee grounds. Make sure that the filter holder is clean and
reposition it in the brewing group to warm up again.
Preparing an espresso with the use of coffee pods:
22. Check that the water tank (1) has been filled in with water by looking at the water level indicator (20).
23. Press the on/off switch (11): the indicator light of the switch (11) and the indicator light (14) will come on. Do
this operation only if the machine is off. If it’s on pass to the following point.
24. As soon as the indicator light (21) comes on, the machine is ready for use. Check the position of the switch
(13): make sure it is on coffee mode (down).
25. Fit the pod filter (18) into the filter holder (8) that has been warmed up by leaving it attached to the brewing
group as described in point 7.
26. Open the single packed pod and pay attention not to damage the pod.
27. Place the pod in its filter (18).
28. Insert the filter holder (8) in the brewing group ring (5), turn it from left to right with force, then put the cup
on the removable water drainage tray (7).
