Specifications SiBE04-401
8 Specifications
1. Specifications
1.1 Cooling Only
1.1.1 High Grade Models
230V, 50Hz
Notes:
MAX. interunit piping length: 20m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Models
Indoor Units FTKS20CVMB(9) FTKS25CVMB(9)(8) FTKS35CVMB(9)(8)
Outdoor Units RKS20CVMB RKS25CVMB RKS35CVMB
Capacity
Rated (Min.~Max.)
kW 2.0 (1.3~3.0) 2.5 (1.3~3.0) 3.4 (1.4~3.8)
Btu/h 6,800 (4,450~10,250) 8,550 (4,450~10,250) 11,600 (4,750~12,950)
kcal/h 1,720 (1,120~2,580) 2,150 (1,120~2,580) 2,920 (1,200~3,270)
Moisture Removal L/h 0.9 1.2 1.9
Running Current (Rated) A 2.8 3.9 4.9
Power Consumption
Rated (Min.~Max.)
W 500 (300~980) 695 (300~980) 1,060 (300~1,300)
Power Factor % 79.6 79.3 94.3
COP (Rated) W/W 4.00 3.60 3.21
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTKS20CVMB(9) FTKS25CVMB(9)(8) FTKS35CVMB(9)(8)
Front Panel Color White White White
Air Flow Rate
m³/min
(cfm)
H 7.7 (272) 7.7 (272) 7.7 (272)
M 5.9 (208) 5.9 (208) 6.0 (212)
L 4.2 (148) 4.2 (148) 4.4 (155)
SL 3.6 (127) 3.6 (127) 3.8 (134)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor OutputW181818
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40
Power Factor % 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195 273×784×195
Packaged Dimensions (W×D×H) mm 834×325×258 834×325×258 834×325×258
Weight kg 7.5 7.5 7.5
Gross Weight kg 11 11 11
Operation
Sound
H/M/L/SL dBA 38 / 32 / 25 / 22 38 / 32 / 25 / 22 39 / 33 / 26 / 23
Sound Power H dBA 56 56 57
Outdoor Units RKS20CVMB RKS25CVMB RKS35CVMB
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#A 1YC23NXD#A 1YC23NXD#A
Motor Output W 600 600 600
Refrigerant
Oil
Type FVC50K FVC50K FVC50K
Charge L 0.375 0.375 0.375
Refrigerant
Type R410A R410A R410A
Charge kg 0.80 0.80 1.00
Air Flow Rate
m³/min
(cfm)
H 34 (1,201) 34 (1,201) 31.3 (1,105)
L 24.8 (876) 24.8 (876) 22.4 (791)
Fan
Type Propeller Propeller Propeller
Motor OutputW313135
Running Current (Rated) A 2.62 3.72 4.72
Power Consumption (Rated) W 460 655 1,020
Power Factor % 76.3 76.6 94.0
Starting Current A 3.5 4.4 5.4
Dimensions (H×W×D) mm 550×765×285 550×765×285 550×765×285
Packaged Dimensions (W×D×H) mm 882×363×589 882×363×589 882×363×589
Weight kg 30 30 32
Gross Weight kg 35 35 38
Operation
Sound
H / L dBA 46 / 43 46 / 43 47 / 44
Sound Power H dBA 61 61 62
Drawing No. 3D044242B 3D044243B 3D044244B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
