Specifications SiBE04-401
12 Specifications
1.1.3 Non-lnverter Models
230V, 50Hz
Notes:
MAX. interunit piping length: 15m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Models
Indoor Units FTN20CVMB9 FTN25CVMB9 FTN35CVMB9
Outdoor Units RN20CVMB9 RN25CVMB9 RN35CVMB9
Capacity
Rated (Min.~Max.)
kW 2.0 2.25 3.15
Btu/h 6,800 7,650 10,750
kcal/h 1,720 1,940 2,710
Moisture Removal L/h 0.9 1.2 1.7
Running Current (Rated) A 3.3 3.7 4.9
Power Consumption
Rated (Min.~Max.)
W 620 700 1,045
Power Factor % 81.7 82.3 92.7
COP (Rated) W/W 3.23 3.21 3.01
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTN20CVMB9 FTN25CVMB9 FTN35CVMB9
Front Panel Color White White White
Air Flow Rate
m³/min
(cfm)
H 7.7 (272) 7.7 (272) 7.7 (272)
M 5.9 (208) 5.9 (208) 6.1 (215)
L 4.2 (148) 4.2 (148) 4.4 (155)
SL — — —
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 18 18 18
Speed Steps 5 Steps and Auto 5 Steps and Auto 5 Steps and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40
Power Factor % 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185 273×784×185
Packaged Dimensions (W×D×H) mm 834×325×258 834×325×258 834×325×258
Weight kg 7.5 7.5 7.5
Gross Weight kg 11 11 11
Operation
Sound
H/M/L/SL dBA 38 / 32 / 26 / — 38 / 32 / 26 / — 39 / 33 / 26 / —
Sound Power H dBA 56 56 57
Outdoor Units RN20CVMB9 RN25CVMB9 RN35CVMB9
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#A 1YC23NXD#A 1YC23NXD#A
Motor Output W 600 600 600
Refrigerant
Oil
Type FVC50K FVC50K FVC50K
Charge L 0.375 0.375 0.375
Refrigerant
Type R410A R410A R410A
Charge kg 0.79 0.79 1.01
Air Flow Rate
m³/min
cfm
H 29 (1,025) 29 (1,025) 27.5 (972)
L— — —
Fan
Type Propeller Propeller Propeller
Motor Output W 25 25 25
Running Current (Rated) A 3.12 3.52 4.72
Power Consumption (Rated) W 580 660 1,005
Power Factor % 80.8 81.5 92.6
Starting Current A 3.3 3.7 4.9
Dimensions (H×W×D) mm 560×695×265 560×695×265 560×695×265
Packaged Dimensions (W×D×H) mm 824×337×599 824×337×599 824×337×599
Weight kg 31 31 33
Gross Weight kg 36 36 38
Operation
Sound
H/L dBA 46 / — 46 / — 48 / —
Sound Power H dBA 61 61 63
Drawing No. 3D044461 3D044462 3D044463
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
