Chapter 1

Layout contents Page

1. CPU socket 1-4

2. DIMM slots 1-5

3. Expansion slots 1-7

4. Fan and Pump headers 1-9

5. Power connectors 1-10

6. M.2 slot 1-11

7. SATA 6Gb/s ports 1-12

USB 3.2 Gen 2 Front Panel connector 1-13

9. USB 3.2 Gen 1 header 1-13

10. USB 2.0 header 1-14

11. AURA Addressable Gen2 header 1-15

12. AURA RGB header 1-16

13. Clear CMOS header 1-17

14. Front Panel Audio header 1-18

15. LED connector 1-18

16. S/PDIF Out header 1-19

17. Speaker header 1-19

18. System Panel header

1-20

19.

Thermal Sensor header

1-21

20. Thunderbolt header 1-22

21.

BIOS FlashBack™ LED

1-22

22.

Q Code LED

1-23

23. Q-LEDs

1-23
