ASUS RS720A-E9-RS24V2
1-3
1.3 System specifications
The ASUS RS720A-E9-RS24V2 features the ASUS KNPP-D32-R server board. The server
supports AMD EPYC™ 7002 Series processors plus other latest technologies through the
chipsets onboard.
(continued on the next page)
Model Name RS720A-E9-RS24V2
Motherboard
KNPP-D32-R
Processor Support
2 x Socket SP3 (LGA 4094)
AMD EPYC™ 7002 Series
xGMI (External Global Memory Interface Link)
Core Logic
System on Chip (SoC)
Memory
Total Slots
32 (8-channel per CPU, 16 DIMM per CPU)
Capacity
Maximum up to 4096GB
Memory Type
DDR4 3200/2933/2666 RDIMM/ LRDIMM/ 3DS LRDIMM
* Refer to ASUS server AVL for the latest update
Memory Size
16GB, 32GB, 64GB (RDIMM)
* Refer to ASUS server AVL for the latest update
Expansion
Slots
Total PCI/PCI-E/
PIKE Slots
8+1
Slot Type
6 x PCIe x16 (Gen3 x8 link) or 3 PCIe (Gen3 x16 link), FH, HL
1 x PCIe x16 (Gen3 x16 link), LP
1 x PCIe x16 (Gen3 x8 link), FH, HL
1 x OCP Mezzanine 2.0 (Gen3 x16 link)
Disk
Controller
SATA Controller
24 x SATA 6Gb/s ports via HBA/RAID card
2 x M.2 connectors (SATA 6Gb/s & PCIe Gen3 x4 link)
SAS Controller
Optional:
ASUS PIKE II 3008 8-port SAS 12Gb/s HBA card
ASUS PIKE II 3108 8-port SAS HW 12Gb/s RAID card
Storage
Bays
I = internal
A or S will be
hot-swappable
24 x 2.5” Hot-swap Storage Bays
(24 x SATA/SAS support via HBA/RAID Card)
Networking LAN
1 x Dual Port Intel
®
I350-AM2 Gigabit LAN controller
1 x Management Port
Optional OCP Adapter:
Up to 100Gb/s Ethernet / InfiniBand Adapter
Graphic VGA
Aspeed AST2500 64MB
Auxiliary Storage Device Bay
(Floppy / Optical Drive)
N/A
