Asus RS720A-E9-RS24V2 [16/156] Internal features

Chapter 1: Product Introduction

1-6

1.6 Internal features

The barebone server includes the basic components as shown.

The barebone server does not include a floppy disk drive. Connect a USB floppy disk drive to

any of the USB ports on the front or rear panel if you need to use a floppy disk.

WARNING

HAZARDOUS MOVING PARTS

KEEP FINGERS AND OTHER BODY PARTS AWAY

1. Redundant Power supply

2. ASUS KNPP-D32-R Server

Board

3. System fans

4. SATA/SAS back panel

5. 24 x 2.5” storage device trays

6. Front panel (hidden)

7. Asset tag (hidden)

A protection film is pre-attached to the front cover before shipping. Please remove the

protection film before turning on the system for proper heat dissipation.
