vi
Contents
Chapter 6: Driver Installation
6.1 Management applications and utilities installation ................................6-2
6.2 Running the Support DVD .........................................................................6-2
6.2.1 Drivers menu tab ......................................................................... 6-3
6.2.2 Utilities menu tab.........................................................................6-3
6.2.3 Manual menu .............................................................................. 6-4
6.2.4 Contact information menu ........................................................... 6-4
6.3 AMD chipset device software installation ...............................................6-5
6.4 Installing the Intel
®
I350-AM2 Gigabit Adapters driver ........................... 6-6
6.5 VGA driver installation ..............................................................................6-8
Appendix
KNPP-D32-R block diagram ................................................................................... A-2
Notices .................................................................................................................... A-3
ASUS contact information ...................................................................................... A-6
