Daikin RXM35R5V1B [62/68] Fault diagnosis using led on outdoor unit pcb
![Daikin RXM35R5V1B [62/68] Fault diagnosis using led on outdoor unit pcb](/views2/1772861/page62/bg3e.png)
15 | Troubleshooting
Installer reference guide
62
RXJ-M(9)_RXA-A(9)_RXM-R(9)_ARXM-R(9)
R32 Split system air conditioners
4P519439-12M – 2021.02
15.4 Fault diagnosis using LED on outdoor unit PCB
LED is… Diagnosis
flashing Normal.
▪ Check the indoor unit.
ON ▪ Turn the power OFF and back ON, and check the LED
within approximately 3 minutes.
If the LED is ON again, the outdoor unit PCB is faulty.
OFF 1 Supply voltage (for power saving).
2 Power supply fault.
3 Turn the power OFF and back ON, and check the
LED within approximately 3 minutes.
If the LED is OFF again, the outdoor unit PCB is
faulty.
DANGER: RISK OF ELECTROCUTION
▪ When the unit is not operating, the LEDs on the PCB are turned off in order to
save power.
▪ Even when the LEDs are off, the terminal block and the PCB may be powered.
