SiBE041011_A Functions
List of Functions 3
1.2 Heat Pump
Category Functions
FTXS60/71GV1B
RXS60F3V1B
RXS71FAV1B
Category Functions
FTXS60/71GV1B
RXS60F3V1B
RXS71FAV1B
Basic Function Inverter (with inverter power control)
z
Health & Clean Air-purifying filter —
Operation limit for cooling (°CDB)
–10
~46
Photocatalytic deodorizing filter —
Operation limit for heating (°CWB)
–15
~18
Air-purifying filter with photocatalytic
deodorizing function
—
PAM control
z
Titanium apatite photocatalytic
air-purifying filter
z
Compressor
Oval scroll compressor —
Air filter (prefilter)
z
Swing compressor
z
Wipe-clean flat panel
z
Rotary compressor — Washable grille —
Reluctance DC motor
z
MOLD PROOF operation —
Comfortable
Airflow
Power-airflow flap — Heating dry operation —
Power-airflow dual flaps
z
Good-sleep cooling operation —
Power-airflow diffuser — Timer WEEKLY TIMER operation
z
Wide-angle louvers
z
24-hour ON/OFF TIMER
z
Vertical auto-swing (up and down)
z
NIGHT SET mode
z
Horizontal auto-swing (right and left)
z
Worry Free
“Reliability &
Durability”
Auto-restart (after power failure)
z
3-D airflow
z
Self-diagnosis (digital, LED) display
z
COMFORT AIRFLOW operation
z
Wiring error check function —
Comfort
Control
Auto fan speed
z
Anti-corrosion treatment of outdoor heat
exchanger
z
Indoor unit quiet operation
z
NIGHT QUIET mode (automatic) — Flexibility
Multi-split / split type compatible indoor unit
z
OUTDOOR UNIT QUIET operation
(manual)
z
INTELLIGENT EYE operation
z
H/P, C/O compatible indoor unit
z
Quick warming function
(preheating operation)
z
Flexible power supply correspondence —
Hot-start function
z
High ceiling application —
Automatic defrosting
z
Chargeless 10 m
Operation Automatic operation
z
Either side drain (right or left)
z
Program dry operation
z
Power selection —
Fan only
z
Remote
Control
5-room centralized controller (option)
z
Lifestyle
Convenience
New POWERFUL operation (non-inverter) —
Inverter POWERFUL operation
z
Remote control adaptor
(normal open pulse contact) (option)
z
Priority-room setting —
Remote control adaptor
(normal open contact) (option)
z
COOL / HEAT mode lock —
DIII-NET compatible (adaptor) (option)
z
HOME LEAVE operation — Remote
Controller
Wireless
z
ECONO operation
z
Wired (option)
z
Indoor unit [ON/OFF] button
z
Signal receiving sign
z
R/C with back light —
Temperature display —
Note:
z
: Holding Functions
— : No Functions
: Lower limit can be extended to –15°C by
turning switch. (facility use only)
Refer to page 117 for detail.
