SiBE041011_A Main Functions
Function and Control 33
1. Press .
2.
3. Press to activate copy mode.
4.
Copy mode
6:00 8:30 17:30 22:00
25˚C 27˚C
6:00 8:30 17:30 22:00
25˚C 27˚C
Program 1 Program 2 Program 3 Program 4
ON OFF ON OFF
[Monday]
Program 1 Program 2 Program 3 Program 4
ON OFF ON OFF
COPY
• A reservation made once can be copied another day of the
week. The whole reservation of the selected day of the week
will be copied.
[Tuesday]
to
[Friday]
Press to confirm the day of the week
to be copied.
• The whole reservation of the selected day of the week
will be copied.
Press to select the destination day of
the week.
