Daikin RKS35F2V1B [146/216] Signal transmission error on outdoor unit pcb

SiBE06-708 Troubleshooting

Service Diagnosis 135

4.26 Signal Transmission Error on Outdoor Unit PCB

Remote

Controller

Display

Method of

Malfunction

Detection

Communication error between microcomputer mounted on the main microcomputer and PM1.

Malfunction

Decision

Conditions



When the data sent from the PM1 can not be received successively for 9 sec.



The abnormality is determined if the above fault conditions occurs once.



Fault counter is reset when the data from the PM1 can be successfully received.

Supposed

Causes



Defective outdoor unit PCB

Troubleshooting

Replace the outdoor unit

PCB.

The cause can be an

external factor other than

the malfunction.

Monitor in long term.

(R5152)

Caution

Be sure to turn off power switch before connect or disconnect connector,

or parts damage may be occurred.

Error again?

YES

Turn the power off and turn it on

again.
