Specifications SiBE06-708
6 Specifications
1. Specifications
1.1 Cooling Only
Note:
The data are based on the conditions shown in the table below.
SL : The silent fan level of the air flow rate setting.
50Hz 220-230-240V
Model
Indoor Units FVXS25FV1B FVXS35FV1B
Outdoor Units RKS25F2V1B RKS35F2V1B
Capacity
Rated (Min.~Max.)
kW 2.5 (1.3~3.0) 3.5 (1.40~3.80)
Btu/h 8,500 (4,400~10,200) 11,900 (4,800~13,000)
kcal/h 2,150 (1,120~2,580) 3,010 (1,200~3,270)
Moisture Removal L/h 1.2 1.9
Running Current (Rated) A 3.5-3.3-3.2 4.9-4.7-4.5
Power Consumption
Rated (Min.~Max.)
W 570 (300~920) 1,020 (300~1,250)
Power Factor % 74.0-75.1-74.2 94.6-94.4-94.4
COP (Rated) W/W 4.39 3.43
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 20.0 φ 20.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FVXS25FV1B FVXS35FV1B
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 8.2 (290) 8.5 (300)
M 6.5 (229) 6.7 (237)
L 4.8 (169) 4.9 (174)
SL 4.1 (146) 4.5 (158)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current A 0.14-0.13-0.12 0.14-0.13-0.12
Power Consumption W 15 15
Power Factor % 48.7-50.2-52.1 48.7-50.2-52.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 600×700×210 600×700×210
Packaged Dimensions (H×W×D) mm 696×786×286 696×786×286
Weight kg 14 14
Gross Weight kg 18 18
Operation
Sound
H/M/L/SL dBA 38 / 32 / 26 / 23 39 / 33 / 27 / 24
Sound Power H dBA 54 55
Outdoor Unit RKS25F2V1B RKS35F2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD 1YC23NXD
Motor Output W 600 600
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Model R-410A R-410A
Charge kg 1.0 1.0
Air Flow Rate m³/min (cfm)
H 33.5 (1,183) 33.5 (1,183)
L 23.4 (826) 23.4 (826)
Fan
Type Propeller Propeller
Motor Output W 23 23
Running Current A 3.4-3.2-3.1 4.8-4.6-4.4
Power Consumption W 555 1,005
Power Factor % 74.2-75.4-74.6 95.1-95.0-95.1
Starting Current A 3.5 4.9
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 617×882×363 617×882×363
Weight kg 34 34
Gross Weight kg 40 40
Operation
Sound
H/L dBA 46 / 43 47 / 44
Sound Power H dBA 61 62
Drawing No. 3D056295 3D056296
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
