SiBE06-708 Specifications
Specifications 9
Note:
The data are based on the conditions shown in the table below.
SL : The silent fan level of the air flow rate setting.
50Hz 220-230-240V
Model
Indoor Units FVXS50FV1B
Outdoor Units
RXS50F2V1B
Cooling Heating
Capacity
Rated (Min.~Max.)
kW 5.0 (1.4~5.6) 5.8 (1.4~8.1)
Btu/h 17,100 (4,800~19,100) 19,800 (4,800~27,600)
kcal/h 4,300 (1,200~4,820) 4,990 (1,200~6,970)
Moisture Removal L/h 2.9
—
Running Current (Rated) A 7.2-6.8-6.6 7.3-7.0-6.7
Power Consumption
Rated (Min.~Max.)
W 1,550 (500~2,000) 1,600 (500~2,600)
Power Factor % 99.2-99.1-99.4 99.6-99.3-99.5
COP (Rated) W/W 3.23 3.63
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 12.7
Drain mm φ 20.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FVXS50FV1B
Front Panel Color White
Air Flow Rate
m³/min
(cfm)
H 10.7 (378) 11.8 (417)
M 9.2 (326) 10.1 (358)
L 7.8 (274) 8.5 (300)
SL 6.6 (233) 7.1 (250)
Fan
Type Turbo Fan
Motor Output W 48
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Upward
Air Filter Removable / Washable / Mildew Proof
Running Current A 0.18-0.17-0.16 0.20-0.19-0.18
Power Consumption W 27 34
Power Factor % 68.1-69.1-70.3 77.3-77.8-78.7
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 600×700×210
Packaged Dimensions (H×W×D) mm 696×786×286
Weight kg 14
Gross Weight kg 18
Operation
Sound
H/M/L/SL dBA 44 / 40 / 36 / 32 45 / 40 / 36 / 32
Sound Power H dBA 56 57
Outdoor Unit RXS50F2V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC36BXD
Motor Output W 1,100
Refrigerant
Oil
Model FVC50K
Charge L 0.65
Refrigerant
Model R-410A
Charge kg 1.5
Air Flow Rate m³/min (cfm)
HH 50.9 (1,797)
—
H 48.9 (1,727) 45.0 (1,589)
L 41.7(1,472) 45.0 (1,589)
Fan
Type Propeller
Motor Output W 53
Running Current A 7.02-6.64-6.44 7.14-6.83-6.54
Power Consumption W 1,523 1,566
Power Factor % 98.6-99.7-98.5 99.7-99.7-99.8
Starting Current A 7.3
Dimensions (H×W×D) mm 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390
Weight kg 48
Gross Weight kg 53
Operation
Sound
H/L dBA 47 / 44 48 / 45
Sound Power H dBA 61 62
Drawing No. 3D056276
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
