SiBE06-708 Specifications
Specifications 7
Note:
The data are based on the conditions shown in the table below.
SL : The silent fan level of the air flow rate setting.
50Hz 220-230-240V
Model
Indoor Units FVXS50FV1B
Outdoor Units RKS50F2V1B
Capacity
Rated (Min.~Max.)
kW 5.0 (1.4~5.9)
Btu/h 17,100 (4,800~19,100)
kcal/h 4,300 (1,200~4,820)
Moisture Removal L/h 2.9
Running Current (Rated) A 7.2-6.8-6.6
Power Consumption
Rated (Min.~Max.)
W 1,550 (500~2,000)
Power Factor % 99.2-99.1-99.4
COP (Rated) W/W 3.23
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 12.7
Drain mm φ 20.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Unit FVXS50FV1B
Front Panel Color White
Air Flow Rate
m³/min
(cfm)
H 10.7 (378)
M 9.2 (326)
L 7.8 (274)
SL 6.6 (233)
Fan
Type Turbo Fan
Motor Output W 48
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current A 0.18-0.17-0.16
Power Consumption W 27
Power Factor % 68.1-69.1-70.3
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 600×700×210
Packaged Dimensions (H×W×D) mm 696×786×286
Weight kg 14
Gross Weight kg 18
Operation
Sound
H/M/L/SL dBA 44 / 40 / 36 / 32
Sound Power H dBA 56
Outdoor Unit RKS50F2V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC36BXD
Motor Output W 1,100
Refrigerant
Oil
Model FVC50K
Charge L 0.65
Refrigerant
Model R-410A
Charge kg 1.5
Air Flow Rate m³/min (cfm)
HH 50.9 (1,797)
H 48.9 (1,727)
L 41.7 (1,472)
Fan
Type Propeller
Motor Output W 53
Running Current A 7.02-6.64-6.44
Power Consumption W 1,523
Power Factor % 98.6-99.7-98.5
Starting Current A 7.2
Dimensions (H×W×D) mm 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390
Weight kg 48
Gross Weight kg 52
Operation
Sound
H/L dBA 47 / 44
Sound Power H dBA 61
Drawing No. 3D056297
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
