Specifications SiBE06-708
8 Specifications
1.2 Heat Pump
Note:
The data are based on the conditions shown in the table below.
SL : The silent fan level of the air flow rate setting.
50Hz 220-230-240V
Model
Indoor Units FVXS25FV1B FVXS35FV1B
Outdoor Units
RXS25F2V1B RXS35F2V1B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.5 (1.3~3.0) 3.4 (1.3~4.5) 3.5 (1.4~3.8) 4.5 (1.4~5.0)
Btu/h 8,500 (4,400~10,200) 11,600 (4,400~17,100) 11,900 (4,800~13,000) 15,400 (4,800~17,100)
kcal/h 2,150 (1,120~2,580) 2,920 (1,120~4,300) 3,010 (1,200~3,270) 3,870 (1,200~4,300)
Moisture Removal L/h 1.2 — 1.9 —
Running Current Rated A 3.5-3.3-3.2 4.5-4.3-4.1 4.9-4.7-4.5 5.9-5.6-5.4
Power Consumption
Rated (Min.~Max.)
W 570 (300~920) 790 (290~1,390) 1,020 (300~1,250) 1,220 (310~1,880)
Power Factor % 74.0-75.1-74.2 79.8-79.9-80.3 94.6-94.4-94.4 94.0-94.7-94.1
COP
Rated (Min.~Max.)
W/W 4.39 4.30 3.43 3.69
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 20 φ 20
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FVXS25FV1B FVXS35FV1B
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 8.2 (290) 8.8 (311) 8.5 (300) 9.4 (332)
M 6.5 (229) 6.9 (244) 6.7 (237) 7.3 (258)
L 4.8 (169) 5.0 (178) 4.9 (174) 5.2 (184)
SL 4.1 (146) 4.4 (155) 4.5 (158) 4.7 (168)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.14-0.13-0.12 0.15-0.14-0.13 0.14-0.13-0.12 0.15-0.14-0.13
Power Consumption (Rated) W 15 17 15 17
Power Factor % 48.7-50.2-52.1 51.5-52.8-54.5 48.7-50.2-52.1 51.5-52.8-54.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 600×700×210 600×700×210
Packaged Dimensions (H×W×D) mm 696×786×286 696×786×286
Weight kg 14 14
Gross Weight kg 18 18
Operation
Sound
H/M/L/SL dBA 38 / 32 / 26 / 23 38 / 32 / 26 / 23 39 / 33 / 27 / 24 39 / 33 / 27 / 24
Sound Power dBA 54 54 55 55
Sound Power H dBA 61 62 62 63
Outdoor Unit RXS25F2V1B RXS35F2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD 1YC23NXD
Motor Output W 600 600
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Model R-410A R-410A
Charge kg 1.0 1.0
Air Flow Rate m³/min (cfm)
H 33.5 (1,183) 30.2 (1,066) 33.5 (1,183) 30.2 (1,066)
L 23.4 (826) 28.3 (999) 23.4 (826) 28.3 (999)
Fan
Type Propeller Propeller
Motor Output W 23 23
Running Current (Rated) A 3.4-3.2-3.1 4.4-4.2-4.0 4.8-4.6-4.4 5.8-5.5-5.3
Power Consumption (Rated) W 555 773 1,005 1,203
Power Factor (Rated) % 74.2-75.4-74.6 80.3-80.0-80.5 95.1-95.0-95.1 94.3-95.1-94.6
Starting Current A 4.5 5.9
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 617×882×363 617×882×363
Weight kg 34 34
Gross Weight kg 40 40
Operation
Sound
H/L dBA 46 / 43 47 / 44 47 / 44 48 / 45
Sound Power dBA 54 54 55 55
Sound Power H dBA 61 62 62 63
Drawing No. 3D056274 3D056275
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
