Instruction Si12-411A
136 System Configuration
■ To adjust the vertical blades
(louvres)
• When adjusting the louvre, use a robust and stable stool and
watch your steps carefully.
Hold the knob and move the louvres.
(You will find a knob on the left side and the right side blades.)
Notes on flap and louvres angles
• Unless [SWING] is selected, you should set the
flap at a near- horizontal angle in COOL or DRY
mode to obtain the best performance.
• In COOL or DRY mode, if the flap is fixed at a
downward position, the flap automatically moves
in about 60 minutes to prevent condensation on it.
■
■■
■
ATTENTION
• Always use a remote controller to adjust the flap
angle.
If you attempt to move it forcibly with hand when it
is swinging, the mechanism may be broken.
• Be careful when adjusting the louvres. Inside the
air outlet, a fan is rotating at a high speed.
DRY
COOL
FAN
HEAT
