Daikin CDXS25CVMA [257/298] Disconnect the fan motor lead wire
![Daikin CDXS25CVMA [257/298] Disconnect the fan motor lead wire](/views2/1777816/page257/bg101.png)
Outdoor Unit (50 / 52 / 58 / 68 / 75 Class) Si12-411A
246 Removal Procedure
2
Remove 1 screw of the
electrical box.
3
Remove the drip-proof
cover.
4
Disconnect the fan
motor lead wire.
5
Lift up the electrical box
and dismount it.
Step
Procedure Points
