Outdoor Unit (80 / 90 Class) Si12-411A
228 Removal Procedure
3
Remove the outdoor air
thermistor lead wire
from the groove.
4
Remove each wire
harness, and dismount
the electrical box by
lifting it.
Step
Procedure Points
