Specifications SiEN18-622
38 Specifications
50Hz 220-230-240V / 60Hz 220-230V
Model
FTXS35EVMA FTXS50FVMA
Cooling Heating Cooling Heating
Rated Capacity 3.5kW Class 5.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 8.9 (314) 9.7 (342) 14.7 (519) 16.2 (572)
M 6.9 (242) 7.9 (277) 12.6 (445) 13.8 (487)
L 4.8 (169) 6.0 (212) 10.2 (360) 11.5 (406)
SL 4.0 (141) 5.2 (184) 9.2 (325) 10.2 (360)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 43
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.19-0.18-0.17 / 0.19-0.18 0.19-0.18-0.17 / 0.19-0.18 0.16-0.15-0.15 / 0.16-0.15 0.17-0.16-0.16 / 0.17-0.16
Power Consumption (Rated) W 40 40 34 36
Power Factor % 95.7-96.6-98.0 / 95.7-96.6 95.7-96.6-98.0 / 95.7-96.6 96.6-98.6-94.4 / 96.6-98.6 98.3-97.8-93.8 / 96.3-97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 290×1,050×238
Packaged Dimensions (H×W×D) mm 265×855×340 337×1,147×366
Weight kg 9 12
Gross Weight kg 12 17
Operation
Sound
H/M/L/SL dBA 38/32/26/23 38/34/29/26 44 / 40 / 35 / 32 42 / 38 / 33 / 30
Sound Power H dBA — 60 59 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ12.7
Drain mm
φ18.0 φ18.0
Drawing No. 3D054407 3D054879
Model
FTXS60FVMA FTXS71FVMA
Cooling Heating Cooling Heating
Rated Capacity 6.0kW Class 7.1kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 16.2 (572) 17.4 (614) 17.4 (614) 21.5 (759)
M 13.9 (491) 15.3 (540) 14.6 (516) 18.0 (636)
L 11.5 (406) 12.8 (452) 11.9 (420) 14.4 (508)
SL 10.0 (353) 10.5 (371) 11.2 (395) 13.3 (470)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.19-0.18-0.17 / 0.19-0.18 0.21-0.20-0.19 / 0.21-0.20 0.21-0.20-0.19 / 0.21-0.20 0.28-0.27-0.26 / 0.28-0.27
Power Consumption (Rated) W 40 45 45 60
Power Factor % 95.7-96.6-98.0 / 95.7-96.6 97.4-97.8-98.7 / 97.4-97.8 97.4-97.8-98.7 / 97.4-97.8 97.4-96.6-96.2 / 97.4-96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 45 / 41 / 36 / 33 44 / 40 / 35 / 32 46 / 42 / 37 / 34 46 / 42 / 37 / 34
Sound Power H dBA 61 60 59 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ12.7 φ15.9
Drain mm
φ18.0 φ18.0
Drawing No. 3D054880 3D054881
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
