Si04-703A Indoor Unit
Removal Procedure 141
3. Remove an “titanium
apatite photocatalytic air
purifying filter”.
1
Push up the bottom of
an air purifying filter to
undo the hooks (2 on
lower, 3 on upper) and
take the filter out.
The right and left filters are
interchangeable.
Step
Procedure Points
