Daikin FTKS71FVM [216/244] Remove the discharge pipe thermistor
![Daikin FTKS71FVM [216/244] Remove the discharge pipe thermistor](/views2/1778473/page216/bgd8.png)
Si04-703A Outdoor Unit
Removal Procedure 205
2
Slightly open the sound
blanket.
3
Remove the sound
blanket (top upper).
4
Remove the discharge
pipe thermistor.
Step Procedure Points
(R7011)
(R7012)
(R6455)
