Daikin FTKS71FVM [220/244] Remove the sound blanket outer sleeve
![Daikin FTKS71FVM [220/244] Remove the sound blanket outer sleeve](/views2/1778473/page220/bgdc.png)
Si04-703A Outdoor Unit
Removal Procedure 209
7
Remove the sound
blanket (outer sleeve).
Step Procedure Points
(R7019)
