SiBE04-302 Indoor Unit
Removal Procedure 151
6
Disengage a hook from
the backward.
7
Since the fan bearing is
made of rubber, push it
strongly off from the
inside. The bearing can
be removed just as the
left-side plate is
attached with.
Step Procedure Points
