Specifications SiBE04-302
14 Specifications
230V, 50Hz
Notes:
MAX. interunit piping length: 15m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Models
Indoor Units FTS20BVMB FTS25BVMB
Outdoor Units RS20BVMB RS25BVMB
Capacity
kW 2.0 2.5
Btu/h 6,850 8,550
kcal/h 1,720 2,150
Moisture Removal L/h 0.9 1.2
Running Current (Rated) A 3.4 4.5
Power Consumption (Rated) W 690 890
Power Factor % 88.2 86.0
COP (Rated) W/W 2.90 2.81
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTS20BVMB FTS25BVMB
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 7.5 (265) 7.8 (276)
M 5.6 (198) 6.0 (212)
L 3.9 (138) 4.2 (148)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimensions (W×D×H) mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L dBA 38 / 32 / 26 39 / 33 / 27
Sound Power dBA H 54 55
Outdoor Unit RS20BVMB RS25BVMB
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23KXA#A 1YC23KXA#A
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.43 0.43
Refrigerant
Type R410A R410A
Charge kg 0.79 0.79
Air Flow Rate
m³/min 29 29
cfm 1,025 1,025
Fan
Type Propeller Propeller
Motor Output W 25 25
Running Current (Rated) A 3.22 4.32
Power Consumption (Rated) W 650 850
Power Factor % 87.8 85.5
Starting Current A 3.4 4.5
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (W×D×H) mm 797×310×599 797×310×599
Weight kg 34 34
Gross Weight kg 37 37
Operation Sound dBA 47 47
Sound Power dBA H 60 60
Drawing No. 3D039743A 3D039744A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
