Daikin ATX35BVMB [168/201] Remove the electrical box
![Daikin ATX35BVMB [168/201] Remove the electrical box](/views2/1780807/page168/bga8.png)
SiBE04-302 Outdoor Unit
Removal Procedure 159
7
The PCB can
completely be released.
3. Remove the electrical box.
1
Remove the two screws
fixing the electrical box.
Step Procedure Points
