ROTARY HAMMER

ATTENTION!

Before installing into the box the shank of the working tool should be lubricated with special grease.

Using the auxiliary handle

You should always use the auxiliary handle supplied with the tool. Losing control of the tool while working may

cause injury.

To install or change the side handle 12 let loose the clamp by counterclockwise rotation of the grip, then install the

handle on the machine in the desired angular position and x it by clockwise rotation of the grip.

Setting the depth of drilling

Using the depth gauge 10 you can set the desired depth of drilling. To do this loosen the wing screw of the mount

of the gauge, set the required processing size (distance from drill bit to the end of the gauge), and tighten the

wing screw.

Power connection

ATTENTION!

The electric tools should be connected only to the single phase AC network which voltage

corresponds to voltage indicated on the labels. This electric tool can be connected to sockets

without earthing protection because it has double insulation (protection class II).

ATTENTION!

Before plugging in make sure the switch is in the "o" position. With long-term storage of the tool

the switch must be in the “o” position.

Power connection indicator 8 turns on when there is a supply voltage on the motor switches and indicates

that the machine is ready for operation. When the indicator is on, be careful; avoid pressing the switch key

unintentionally.

Before using the electrical rotary hammer you must:

• inspect and verify its completeness and no external damage;

• after transportation in winter conditions before turning on, leave at room temperature until complete drying

of water condensate;

• after a long break (especially when operating at low temperatures), it is necessary to warm up the electrical

rotary hammer by idling during 1-2 minutes.

Before getting started you must:

• check the service ability of the used working tool;

• install the working tool, previously the shank of the working tool should be lubricated with special grease;

• if it is necessary use the dust collector supplied in the set. The dust collector is put on the tool shank before

installing it into the box of the electrical rotary hammer and prevents dust from getting into the box and its

premature wear o;

• when using a chisel establish a comfortable position of the working edge relative to the electrical rotary hammer

housing. To do this switch the operation mode switch 4 to , turn the chisel by hand to a comfortable position

(the chisel should turn with the barrel without much eort). After adjusting the chisel position set the operation

mode switch 4 to , at the same time the barrel will be blocked from turning.

ATTENTION!

When setting the chisel position do not turn on the electrical rotary hammer motor, unplug the

power cord from the power outlet to avoid injury and damage to the mechanism.

• install the side handle in a comfortable work position;

• set and x depth gauge;
