ED18-730 Features
Features 5
1
Refrigerant Piping
Main piping
BP unit
BP unit
Branch piping
Branch piping
≤
135
m(55+80)
Total piping length
≤
80
m
Total branch piping length
(between BP unit — Indoor unit)
≤
55
m
Total main piping length
(between Outdoor unit — BP unit)
Max. height
difference
30m
Note) Refrigerant charge is necessary.
(ex. 5HP)
≤
135
m(55+80)
Total piping length
≤
80
m
Total branch piping length
(between BP unit — Indoor unit)
Total main piping length
(between Outdoor unit — BP unit)
≤
55
m
06RAG09-28
Refrigerant
Piping
15mPiping length BP – I/U (f,g,h,i,j,k,l,m)
40mPiping length 1
st
branch – I/U (ex. b+c+m)
55mTotal main piping length *1 (O/U - BP: a+b+c+d+e)
90m80m60mTotal branch piping length *2 (f+g+h+i+j+k+l+m)
145m
6HP
6HP
135m115mTotal piping length ( *1+*2 )
5HP
5HP
4HP
4HP
Max. Inter-unit Piping Length
Max. Inter-unit Piping Length
Max. height
1
st
Branch
difference
30m
Note) The pipe size of branch – BP varies according to the capacity of
I/Us connected to the BP. (for oil return operation)
15mPiping length BP – I/U (f,g,h,i,j,k,l,m)
40mPiping length 1
st
branch – I/U (ex. b+c+m)
55mTotal main piping length *1 (O/U - BP: a+b+c+d+e)
90m80m60mTotal branch piping length *2 (f+g+h+i+j+k+l+m)
145m135m115mTotal piping length ( *1+*2 )
06RAG09-29
Heating operation
lower limit
-15°CWB
50
40
30
20
10
0
-10
-20
46°CDB
- 5°CDB
Cooling Heating
15.5°CWB
- 15°CWB
Operation Range
06RAG09-30
