Features ED18-730
6 Features
1.2 Selection Procedure
1.2.1 Outdoor Unit
1.2.2 Indoor Unit
1.2.3 Decoration Panel
A decoration panel is required for SkyAir models.
1.2.4 Remote Controller
Choose the suitable remote controller for SkyAir models.
1.2.5 BP Unit
1.2.6 REFNET JOINT
1.2.7 Option
You can choose various optional accessories for control system, indoor unit, and outdoor unit.
(→See "Part 6 Options" for details.)
Cooling only Heat pump
Model name RMKS112E RMKS140E RMKS160E RMXS112E RMXS140E RMXS160E
Type 4HP 5HP 6HP 4HP 5HP 6HP
Rated capacity (kW) Cooling 11.2 14.0 15.5 11.2 14.0 15.5
Heating — — — 12.5 16.0 17.5
Connectable indoor
units
Maximum number
of indoor units
5 units 7 units 8 units 5 units 7 units 8 units
Total indoor unit
capacity (kW)
5.5-14.5 7.0-18.2 8.0-20.8 5.5-14.5 7.0-18.2 8.0-20.8
Maximum number of connectable BP units 3 units
Cooling only Heat pump
Type 25 35 50 60 71 25 35 50 60 71
Rated capacity (kW) 2.5 3.5 5.0 6.0 7.1 2.5 3.5 5.0 6.0 7.1
RA
Wall mounted FTK(X)S
Duct connected
(Slim compact)
FDKS ————————
CDXS ————————
Duct connected (Slim) FDK(X)S — —
SA
Ceiling mounted
cassette (950×950)
FCQ — —
Ceiling mounted built-in FBQ — — — ———
Ceiling mounted cassette
(950×950)
FCQ BYC125K-W1
Ceiling mounted built-in FBQ BYBS71DJW1
Cooling only Heat pump
Wireless remote controller FCQ BRC7C613W BRC7C612W
FBQ — —
Wired remote controller FCQ
BRC1C61
FBQ
Cooling only Heat pump
Model name BPMKS967A2 BPMKS967A3 BPMKS967A2 BPMKS967A3
Type 2 rooms 3 rooms 2 rooms 3 rooms
Maximum capacity (kW) 14.2 20.8 14.2 20.8
Maximum number of BP units for 1 system 3 units
Model name KHRP26M22T
Number of BP units 1 Not necessary
2 KHRP26M22T×1
3 KHRP26M22T×2
