Specifications ED18-730
26 SUPER MULTI PLUS E-Series Cooling Only
50Hz 230V
Note:
1.
See Page 20 “Combination Capacity”.
2. The operating sound is based on the rear side suction inlet and the external static pressure 30 Pa.
Operating sound for under side suction inlet: [operating sound for rear side suction inlet]+6 dB.
However, when installation to which the external static pressure becomes low is carried out,
6 dB or more may go up.
Model FDKS25EAVMB FDKS35EAVMB
Rated Capacity
2.5kW Class 3.5kW Class
Front Panel Color
——
Air Flow Rates
m³/min
(cfm)
H 8.7 (307) 8.7 (307)
M 8.0 (282) 8.0 (282)
L 7.3 (258) 7.3 (258)
SL 6.2 (219) 6.2 (219)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.48 0.48
Power Consumption (Rated) W 71 71
Power Factor % 64.3 64.3
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 200×700×620 200×700×620
Packaged Dimensions (H×W×D) mm 274×906×751 274×906×751
Weight kg 21 21
Gross Weight kg 29 29
Operation
Sound
H/M/L/SL dBA 35/33/31/29 35/33/31/29
External Static Pressure Pa 30 30
Moisture Removal L/h 1.2 1.9
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm VP20 (O.D.
φ
26 / I.D.
φ
20) VP20 (O.D.
φ
26 / I.D.
φ
20)
Drawing No. 3D051882A 3D051884A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
