DETAILED DESCRIPTION OF THE OBJECTS

COMMON TO ALL OBJECTS

For each Airzone system:

1. When the indoor unit is communicating normally, a communication can be established between the Airzone BACnet

Interface and the indoor unit. The BACnet building management system will then have access to the Airzone unit’s

objects.

2. If the communication between the Airzone BACnet Interface and the system is not correct, or if a request for

information related to a communication object that is not present in the Airzone system the object's property "Out of

service" is activated.

Z# ALARM INPUT

This object represents the state of alarm input available to the Airzone main board (normally closed contact), indicating

whether this input is active or inactive. When this input is active, the system remains in STOP. This is a Read only object.

Z# RADIANT STAGE

This object displays if the radiant stage is activated or deactivated in each zone. This is a Read only object.

Important: the following combinations will not generate air:

- Airzone-xxx Gateway Communication (AZX6QADAPTxxx) on Flexa 3.0, Innobus Pro6, Acuazone and Innobus Pro32

main control boards.

- Airzone-Electromechanical Unit Control Gateway (AZX6ELECTROMEC) on Flexa 3.0, Innobus Pro6, Acuazone and

Innobus Pro32 main control boards.

- Wired/wireless individual unit infrared zone module (AZDI6MCIFR [C/R]) on Acuazone and Innobus Pro32 systems

configured as zoning system or mixed.

- Wired/wireless individual unit zone module xxx (AZDI6MCxxx [C/R]) on Acuazone and Innobus Pro32 systems

configured as zoning system or mixed.

Important: the following combinations will not generate radiant demand:

- Wired/wireless zoning module for electrical heating element (AZDI6MZSRE [C/R] on Acuazone and Innobus Pro32.

AIR/RADIANT DEMAND

This object displays if there is cooling or heating demand in air or radiant stage. This is a Read only object.

Z# ON/OFF

The Airzone BACnet Interface will report the status of each zone. Using the BACnet platform, any zone may be configured as

on/off. These are Read/Write objects.

Z# ROOM TEMPERATURE

The BACnet platform can obtain the actual room temperature for any zone. These are read only objects.

Z# HUMIDITY

The BACnet platform can obtain the actual humidity for each zone. These are read only objects.
