Z# SET POINT

Each thermostat can be configured for a determined set point, and those values are reported to the BACnet platform, and can

be changed from it. These are Read/Write objects.

Allowed values may be limited based on the selected Eco-Adapt of the Airzone system:

Cooling: 18-30 °C. Heating: 15-30 °C.

Cooling: 24-30 °C. Heating: 15-22 °C.

Cooling: 25-30 °C. Heating: 15-21,5 °C.

Cooling: 26-30 °C. Heating: 15-21 °C.

Z# OPERATION MODE

The Airzone BACnet Interface will report the operation mode of the system or the operation mode of each zone (depending on

the connected system), represented by a number. These are Read/Write objects. These modes are:

0 à Stop

2 à Cooling

3 à Heating

4 à Dry

6 à Ventilation

In VRV Heat Pump installations, all the indoor units must work in supported/compatible operation modes, the operation mode

of the Airzone connected to a slave indoor unit could be restricted or limited by the operation mode selected in the Airzone

connected to the master indoor unit.

If in the same VRV Heat Pump installation, an Airzone unit is connected to a slave indoor unit and another indoor unit is

configured as the master (with or without Airzone connected to):

- When the master IU is operating in Fan mode, the Airzone system will send the current mode (cool, heat or dry) to the

BACnet interface, if a cooling or heating demand exits.

- If no cooling or heating demand exits, the Airzone system will report STOP to the BACnet Interface.

Z# FANCOIL SPEED

This parameter refers to the Fancoil Unit fan speed. The Airzone BACnet Interface will report the system speed of each zone

(depending on the connected system), represented by a number. These are Read/Write objects:

0 à Stop

1 à Speed 1

2 à Speed 2

3 à Speed 3
