[Table 1: Test Operation PC's Current Address]

2. Change the test operation PC's IP address. Use one of the following IP address depending on the current status of the

Interface for use in BACnet®. If the Interface for use in BACnet®’s IP address has not been changed from the factory

setting, use the following:

- Port: 47808

- IP Address: DHCP

- Subnet Mask: 255.255.255.0

- Gateway IP: 192.168.0.1

If the Interface for use in BACnet®’s IP address has been changed from the factory setting at the site, use the

following:

- IP address shown in the table in "[6]-2. IP address temporarily used for the test service operation" on P.12.

2.1. Enter the information above in "IP address" [3], "subnet mask" [4], and "default gateway" [5] in the dialog

box 2 of Step 1-3, and press the OK button [6]. The dialog box 1 reappears. Click the OK or Cancel button

[7].

2.2. Reboot the PC as required by the PC. (Reboot may not be necessary depending on the Windows version.

Reboot the PC only when requested).

3. Return the IP address to the original address after the test operation. (Be sure to return the test operation PC's IP address

to the original address).

3.1. Return the test operation PC's IP address to the original address recorded in Step 1-3, as instructed in

Steps 2-1 and 2-2.

[3] IP Address

Ej. 150.35.20.60

[4] Subnet mask

Ej. 255.255.255.0

[5] Default gateway address

Ej. 15.35.20.254

Dialog box 1. Local Area Connection Properties Dialog box 2. Internet Protocol (TCP / IP) Properties
