Korting KHC6751X [6/36] Use and maintenance

•Fixingthedecorativetelescopicue:

Arrange the electrical power supply within the dimensions of

the decorative ue. If your appliance is to be installed in the

ducting version or in the version with external motor, prepare

the air exhaust opening. Adjust the width of the support

bracket of the upper ue (Fig.3). Then x it to the ceiling using

the screws A (Fig.3) in such a way that it is in line with your

hood and respecting the distance from the ceiling indicated

in Fig.2. Connect the ange C to the air exhaust hole using a

connection pipe (Fig.4). Insert the upper ue into the lower

ue. Fix the lower ue to the hood using the screws B provided

(Fig.4), extract the upper ue up to the bracket and x it with

the screws B (Fig.3). To transform the hood from a ducting

version into a ltering version, ask your dealer for the charcoal

lters and follow the installation instructions.

•Filteringversion:

Install the hood and the two flues as described in the

paragraph for installation of the hood in ducting version. To

assemble the ltering ue refer to the instructions contained

in the kit. If the kit is not provided, order it from your dealer

as accessory. The lters must be applied to the suction unit

positioned inside the hood. They must be centred by turning

them 90 degrees until the stop catch is tripped (Fig.7).

USE AND MAINTENANCE

•We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance is

left running for 15 minutes after the food is cooked, in order

to thoroughly eliminate all contaminated air.

The eective performance of the cooker hood depends on

constant maintenance; the anti-grease lter and the active

carbon lter both require special attention.

•Theanti-greaselter is responsible retaining the grease

particles suspended in the air, therefore it is subject to

clogging with variable frequency according to the use of the

appliance.

- To prevent the danger of possible res, at least every 2

months one must wash the anti-grease lters by hand using

non-abrasive neutral liquid detergents or in the dishwasher

at low temperatures and on short cycles.

- After a few washes, colour alterations may occur. This does

not give the right to claim their replacement.

•Theactivecarbonlters are used to purify the air that is

sent back into the room and its function s to mitigate the

unpleasant odours produced by cooking.

- The non-regenerable active carbon lters must be replaced

at least every 4 months. The saturation of the active charcoal

depends on the more or less prolonged use of the appliance,

on the type of kitchen and on the frequency with which anti-

grease lter is cleaned.

- Regenerable active charcoal lters must be washed by hand,

with non abrasive neutral detergents, or in the dishwasher at

a maximum temperature of 65°C (the washing cycle must be

complete without dishware). Remove excess water without

damaging the lter, remove the plastic parts, and let the mat

dry in the oven for at least 15 minutes approximately at a

maximum temperature of 100°C. To keep the regenerable

charcoal lter functioning ecient this operation must be

repeated every 2 months. These must be replaced at least

every 3 years or when the mat is damaged.

•Beforeremountingtheanti-greaseltersandtheregen-

erableactivecharcoalltersitisimportantthattheyare

completely dry.

•Cleanthehoodfrequently,bothinternallyandexter-

nally, using a cloth dampened with denatured alcohol or

neutral liquid detergents that are non abrasive.

•The lighting .system is designed for use during cooking

and not for the prolonged general lighting of the room. The

prolonged use of the lighting system signicantly decreases

the average duration of the bulbs.

•If the appliance is equipped with courtesy lights it is possible

to use them for general room lighting for a prolonged amount

of time.

•Attention: the non compliance with the hood cleaning

warnings and with the replacement and cleaning of the lters

entails risk of res. One therefore recommends keeping to the

suggested instructions.

•Replacinghalogenlightbulbs(Fig.8A):

To replace the halogen light bulbs B, remove the glass pane

C using a lever action on the relevant cracks.

Replace the bulbs with new ones of the same type.

Caution: do not touch the light bulb with bare hands.

•Replacingthehalogen/incandescentlamps(Fig.8B):

Only use lamps of the same type and wattage installed on

the device.

•Commands(Fig.9)mechanical the key symbols are ex-

plained below:

A = LIGHT

B = OFF

C = SPEED I

D = SPEED II

E = SPEED III.

•Commands(Fig.10)luminous the key symbols are ex-

plained below:

A = LIGHT

B = OFF

C = SPEED I

D = SPEED II

E = SPEED III

F = AUTOMATIC STOP TIMER - 15 minutes (*)

If your appliance does not have the INTENSIVE speed

function, press key E for two seconds and it will be activated

for 10 minutes after which it will return to the previously set

speed. When the function is active the LED ashes. To interrupt

it before the 10 minutes have expired press key E again.

By pressing key F for two seconds (with the hood switched

o ) the “clean air” function is activated. This function switches

the appliance on for ten minutes every hour at the rst speed.

As soon as this function is activated the motor starts up at the

rst speed for ten minutes. During this time key F and key

C must ash at the same time. After ten minutes the motor

switches o and the LED of key F remains switched on with

a xed light until the motor starts up again at the rst speed

after fty minutes and keys F and C start to ash again for ten

minutes and so on. By pressing any key for the exclusion of

the hood light the hood will return immediately to its normal

functioning (e.g. if key D is pressed the “clean air” function is

deactivated and the motor moves to the 2nd speed straight

away. By pressing key B the function is deactivated).

(*) The “AUTOMATIC STOP TIMER” delays stopping of the

hood, which will continue functioning for 15 minutes at the

operating speed set at the time this function is activated.

•Activecarbon/greaseltersaturation:

- When button A ashes at a frequency of 2 seconds, the

- 6 -
