GI-4
PRECAUTIONS
● Combination meter
● EPS control unit
LHD MODELS
● BCM (Models without Intelligent Key system)
● Intelligent Key unit (Models with Intelligent Key system)
● ECM
Precautions for Procedures without Cowl Top Cover
BAS0002G
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
General Precautions
BAS0002H
● Do not operate the engine for an extended period of time without
proper exhaust ventilation.
Keep the work area well ventilated and free of any inflammable
materials. Special care should be taken when handling any
inflammable or poisonous materials, such as gasoline, refriger-
ant gas, etc. When working in a pit or other enclosed area, be
sure to properly ventilate the area before working with hazard-
ous materials.
Do not smoke while working on the vehicle.
● Before jacking up the vehicle, apply wheel chocks or other tire
blocks to the wheels to prevent the vehicle from moving. After
jacking up the vehicle, support the vehicle weight with safety
stands at the points designated for proper lifting before working
on the vehicle.
These operations should be done on a level surface.
● When removing a heavy component such as the engine or
transaxle/transmission, be careful not to lose your balance and
drop them. Also, do not allow them to strike adjacent parts,
especially the brake tubes and master cylinder.
● Before starting repairs which do not require battery power:
Turn off ignition switch.
Disconnect the negative battery terminal.
● If the battery terminals are disconnected, recorded memory of
radio and each control unit is erased.
PIIB3706J
SGI285
SGI231
SEF289H
