6 Technical data
Installation manual
16
RZAG71~140L7V1B
Split system air conditioners
4P418662-1 – 2016.02
RC Signal receiver circuit
S1PH-A Automatic high pressure switch
S1PH-M Manual high pressure switch
S1PL Low pressure switch
TC Signal transmission circuit
V1D~V3D Diode
V1R IGBT power module
V2R Diode module
V1T, V2T Insulated Gate Bipolar Transistor (IGBT)
X1M Terminal strip
Y1E Electronic expansion valve
Y3E Electronic expansion valve
Y1S Solenoid valve (4‑way valve)
Y2S Solenoid valve
Z1C~Z6C Noise filter (ferrite core)
Z1F~Z3F Noise filter
Legend for wiring diagram RZAG100~140:
A1P Printed circuit board (main)
A2P Printed circuit board
BS1~BS4 Push button switch
C1~C3 Capacitor
DS1 DIP switch
E1H Bottom plate heater (option)
F1U~F4U Fuse
F6U Fuse (T 5.0A / 250V)
F7U, F8U Fuse (F 1.0A / 250V)
H1P~H7P Light‑emitting diode (service monitor is orange)
HAP Light-emitting diode (service monitor is green)
K1R Magnetic relay (Y1S)
K2R Magnetic relay (Y2S)
K10R Magnetic relay
K11M Magnetic contactor
K13R~K15R Magnetic relay
K4R Magnetic relay E1H (option)
L1R~L3R Reactor
M1C Motor (compressor)
M1F Motor (fan) (upper)
M2F Motor (fan) (lower)
PS Switching power supply
Q1DI Earth leakage circuit breaker (30mA)
R1~R5 Resistor
R1T Thermistor (air)
R2T Thermistor (discharge)
R3T Thermistor (suction)
R4T Thermistor (heat exchanger inlet)
R5T Thermistor (heat exchanger middle)
R6T Thermistor (liquid)
R7T Thermistor (fin)
RC Signal receiver circuit
S1PH-A Automatic high pressure switch
S1PH-M Manual high pressure switch
S1PL Low pressure switch
TC Signal transmission circuit
V1D~V4D Diode
V1R IGBT power module
V2R Diode module
V1T~V3T Insulated Gate Bipolar Transistor (IGBT)
X1M Terminal strip
Y1E Electronic expansion valve
Y3E Electronic expansion valve
Y1S Solenoid valve (4‑way valve)
Y2S Solenoid valve
Z1C~Z6C Noise filter (ferrite core)
Z1F~Z6F Noise filter
