12
GB
Residual risks
Even if you use this tool in accordance with
instructions, certain residual risks cannot be
eliminated. The following hazards may arise in
connection with the equipment’s construction and
layout:
1. Risk of pinching.
2. Risk of injury from staples.
3. Damage to hearing, if no suitable ear protection is
applied.
4. Health damage caused by hand-arm vibrations, if
the equipment is not properly guided and
maintained.
2. Layout (Fig. 1/8)
A Trigger lever
B Compressed air connection
C Magazine lever
D Magazine cover
E Magazine
F Level indicator
G Depth setting
H Trigger catch
I Cover plate (external)
J Cover plate (Internal)
K Swivel air-outlet
3. Items supplied (Fig. 2)
M Special compressed air oil
N Allen key, 3 mm
O Allen key, 4 mm
4. Intended use
The stapler is a pneumatically operated tool designed
for versatile use.
This equipment is designed for driving finishing nails
and staples into wood and similar materials. Only use
the types of nails/staples described in the “Technical
data” section or illustrated on the information sign on
the magazine. Never use any other nails/staples.
Never use on hard surfaces such as stone, metal,
etc., either.
The equipment may only be used for the tasks it is
designed to handle. Any other use is deemed to be a
case of misuse. The user/operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial
businesses or for equivalent purposes.
Only allow repairs and services to be carried out by
authorized professional repair shops.
Remember.
If the inner diameter of the hose is insufficient
and the length of the hose too long, this will
result in a loss of power on the equipment.
4. Technical data
Max. permitted operating pressure 8.3 bar
Recommended pressure range 6.3 bar
Air consumption approx. 0.66 l/shot
Staple width 5.7 mm
Staple length 13 - 40 mm
Nail length 10 - 50 mm
Recommended hose diameter Diameter 9 mm
Weight approx. 1,5 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 12549, EN ISO 4871.
L
pA
sound pressure level 83.5 dB(A)
K
pA
uncertainty 2.5 dB
L
WA
sound power level 96.5 dB(A)
K
WA
uncertainty 2.5 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with ISO 8662-11-1999,
EN 12096.
Vibration emission value a
h
= 2.5 m/s
2
K uncertainty = 26.8%
These values for noise emissions are equipment-
based characteristic values and do not reflect the
noise generated at the place of use. The noise
generated at the place of use will depend, for
example, on the work area, the workpiece, workpiece
support and the number of stapling/nailing
operations.
