4 Set-up and installation
Installation and operating instructions
10
Daikin FLOSTO150
Hot water storage tank
008.1632099_00 – 03/2019 – EN
4 Set-up and installation
4.1 Installation
4.1.1 Important information
CAUTION
▪ Only install the hot water storage tank if an adequate
ground load-bearing capacity of (500kg/m² plus a
safety factor) is guaranteed. The ground must be flat
and level.
▪ Installation outdoors is only possible to a limited extent.
The storage tank must not be exposed to continuous
direct sunlight as the UV radiation and the effects of
the weather will damage the housing.
▪ The hot water storage tank must be protected from
frost.
▪ Make sure that the supply company does not provide
corrosive domestic water.
Suitable water treatment may be required.
Requirement: The installation location meets the applicable coun-
try-specific requirements.
Incorrect set-up and installation would void the manufacturer's guar-
antee for the device. If there are any questions, please contact our
Technical Customer Service.
4.1.2 Scope of delivery
E
F
Fig.4-1 Scope of delivery
Item Designation
A Storage tank cladding – side panel
B Storage tank cladding – side panel
C Storage tank cladding – lid
D Storage tank cladding – front panel
E Small accessories: Clips for side panels, screws
F Documentation
Tab.4-1
4.1.3 Installing the hot water storage tank
▪ Remove the packaging and dispose of it in an environmentally
sound manner.
▪ Carefully transport the hot water storage tank to the installation
location using the recessed grips.
▪ Install the hot water storage tank at the installation location.
Recommended distance from the wall (a): ≥500mm (Fig. 4-3).
INFORMATION
For the installation of an optional electric immersion
heater (see Chap. 3.2.1), a minimum distance "X" of
≥500mm is required.
INFORMATION
When installing the unit in a cabinet, behind panels or in
other restricted conditions, sufficient ventilation (e.g. using
ventilation gratings) must be ensured.
▪ Check the horizontal position. Slight unevennesses can be com-
pensated by four height-adjustable feet.
Fig.4-2 Height-adjustable feet
