![Bomann WA 509 CB [23/36] Cleaning](/views2/1080088/page23/bg17.png)
ENGLISH
ENGLISH
23
6. The desired baking temperature can be set with the selector.
NOTE:
• The baking process lasts approx. 3-4 minutes.
• This may vary depending on the consistency of the
mixture.
• If your waffl es are too dark, turn the control to a lower
setting.
7. The waffl es can be removed with a wooden fork or similar
item.
CAUTION:
Do not use sharp objects to avoid ruining the coating of
the baking surface.
8. Serve the waffl es on a tray or in a disk and coat with some
powdered sugar.
9. Lightly grease the baking surfaces again as required after
each baking process.
10. The baking surfaces must always be kept closed during
pauses in the baking.
Stopping Operation
To turn the machine off, move the temperature control to 0 (off)
and then remove the plug from the socket. The control lamps
go off.
Recipe for waffl es
5 egg yolks, 5 dessertspoons of hot water, 100 g sugar and
1 grated lemon peel should be mixed together until frothy and
then a mixture of 1/2 teaspoon baking powder and 150 g fl our
should be stirred in. Beat the 5 egg whites stiff and fold them
into the batter.
You can fi nd further recipes in our recipe books or else you can
use a ready-made baking mix.
Cleaning
WARNING:
• Pull out the mains plug and allow the unit to cool down.
• The machine must never be immersed in water!
CAUTION: Do not use abrasive detergents.
• Brush off the crumbs or residues from the baking surfaces
and the edges.
• Clean the machine only with a slightly damp cloth.
Troubleshooting
Malfunction Possible Causes Remedy
The device
does no
t work.
The device has no
power supply.
Check the socket
with another device
and insert the mains
plug properly.
The temperature
control is turned to 0.
Turn the temperature
control to one of the
other levels.
Malfunction Possible Causes Remedy
The red power-
on light does
not come on.
The power supply
has been interrupted.
Insert the plug into
the socket.
The device is broken.
The waffl es
are varying
degrees of
brown.
The lid is not correct-
ly attached as too
little batter has been
poured in.
Fill in and distribute
the correct amount
of batter.
The batter has
overfl ow.
You have poured into
much batter.
Fill in and distribute
the correct amount
of batter.
The waffl es
are too light.
The set temperature
is too low.
Select a higher
control setting.
The waffl es
are too dark.
The level set is too
low.
Turn down the
control.
Technical Data
Model: ..........................................................................WA 509 CB
Power supply: ............................................................230 V, 50 Hz
Power consumption: ............................................................ 850 W
Protection class: ........................................................................... Ι
Net weight: .........................................................................1.14 kg
This device has been tested according to all relevant current
CE guidelines, such as electromagnetic compatibility and low
voltage directives, and has been constructed in accordance with
the latest safety regulations.
Subject to technical changes without prior notice!
Meaning of the “Dustbin” Symbol
Protect our environment: do not dispose of electrical equipment
in the domestic waste.
Please return any electrical equipment that you will no longer
use to the collection points provided for their disposal.
This helps avoid the potential effects of incorrect disposal on the
environment and human health.
This will contribute to the recycling and other forms of reutilisati-
on of electrical and electronic equipment.
Information concerning where the equipment can be disposed of
can be obtained from your local authority.
05-WA 509 CB.indd 2305-WA 509 CB.indd 23 10.09.2008 15:07:35 Uhr10.09.2008 15:07:35 Uhr
