pRack PR300T +0300018EN rel. 1.5 - 02.05.2017
Mask index Display description Description Def. U. of M.Values
The following parameters refer to line 2, for details, see the corresponding parameters for line 1 above
Cba01 DI Alarm 1 compressor 1 DI position (line 2) 03 --- --- | 01…18
U1…U10 (****)
Status (display only) Status Alarm 1 compressor 1 DI (line 2) --- --- closed | open
Logic Logic alarm 1 compressor 1 DI (line 2) NC --- NC | NO
Function (display only) Alarm 1 compressor 1 function status (line 2) --- --- not active | active
…… … ………
Cbb01 Regulation Compressor control by temperature or pressure (line 2) pressure --- pressure
temperature
Reg. Type Compressor regulation type (line 2) dead zone --- Proportion. band
dead zone
…… … ………
Cbc01 Compressor 1 operating
hours
Compressor 1 operating hours (line 2) --- --- 0…999999
…… … ………
Cbd01 Enable suction setpoint
compensation
Enable setpoint compensation (suction line 2) NO --- NO | YES
…… … ………
Cbe01 Number of alarms for each
compressor
Number of alarms for each compressor (line 2) 1 --- 0…4
…… … ………
Cbf02 Compressor type Type of compressors (line 2) Recriproc. --- Recriprocating
scroll
Number of compressors Number of compressors (line 2) 2/3 (*) --- 1…12
…… … ………
Cbg01 Minimum voltage Voltage corresponding to the minimum capacity of the inverter (line 2) 0.0 Hz 0.0…10.0
Maximum voltage Voltage corresponding to the maximum capacity of the inverter (line 2) 10.0 Hz 0.0…10.0
Nominal freq. Nominal frequency (frequency at nominal capacity) (line 2) 50 Hz 0…150
Nominal power Nominal capacity for compressor managed by inverter at nominal frequency (line 2) 10.0 Kw 0.0…500.0
…… … ………
Cca02 RPRV opening Flash gas valve opening percentage to enable parallel line activation 30 % 0…100
Delay Evaluation time for activation of parallel line from when reaching the set ash valve
opening
10 s …
Min g.c. temp Activation threshold relative to gas cooler outlet temperature 25°C °C/°F …
Tgc o thr Parallel compression or parallel compressor line deactivation threshold relative to gas cooler
outlet temperature
15°C °C/°F …
Cca03 RPRV o set with par. comp.
on
O set applied to receiver pressure set point when at least one parallel compressor is active 2.0 barg barg/psig …
Par. Comp. ON rising time
RPRV
Time needed to add the o set to the receiver pressure set point 0 s …
Par. Comp. OFF falling time
RPRV
Time needed to subtract the o set from the receiver pressure set point 20 s …
Cca04 Setpoint Set point for proportional control of integrated parallel compressor on the main board 35 barg barg/psig
Prop gain Proportional gain for proportional control of integrated parallel compressor on the main
board
10 % 0…100
Ti Integral time for proportional control of integrated parallel compressor on the main board 30 s …
Td Derivative time for proportional control of integrated parallel compressor on the main
board
0s…
Cca05 Min.time on Minimum integrated parallel compressor ON time 30 s 0…999
Min.time o Minimum integrated parallel compressor OFF time 120 s 0…999
Min.time on
same compr.
Minimum time between starts of same integrated parallel compressor 360 s 0…999
Cca06 Minimum voltage Voltage corresponding to minimum power of the integrated parallel compressor inverter 0.0 V 0.0…10.0
Maximum voltage Voltage corresponding to maximum power of the integrated parallel compressor inverter 10.0 V 0.0…10.0
Nominal freq. Minimum integrated parallel compressor inverter frequency 30 Hz 0…150
Nominal power Maximum integrated parallel compressor inverter frequency 60 Hz 0…150
Cca07 Nominal freq. Nominal frequency (frequency at nominal power) of the integrated parallel compressor 50 Hz 0…150
Rising time Time to move from integrated parallel compressor modulating device minimum to
maximum power
20 s 0…600
Falling time Time to move from integrated parallel compressor modulating device maximum to
minimum pow
er
20
s 0…600
Cca11 Delay Integrated parallel compressor generic alarm activation delay 0 s 0…999
Delay at start Integrated parallel compressor generic alarm activation delay at start-up 0 s 0…999
Reset Type of integrated parallel compressor generic alarm reset automatic … automatic
manual
Priority light … light | serious
Cca12 DI Integrated parallel compressor generic alarm DI input position --- --- 01…18, U1…U10
Status Integrated parallel compressor generic alarm DI status --- --- closed | open
Logic Integrated parallel compressor generic alarm DI logic NC --- NC | NO
Function Integrated parallel compressor generic alarm function status --- --- not active | active
Eia14 Comp. Par. disch. Temp Integrated parallel compressor discharge temperature --- --- U1…U10
Cca08 Threshold High discharge temperature alarm activation threshold for the integrated parallel
compressor
120°C °C/°F ---
Di erent. High discharge temperature alarm activation di erential for the integrated parallel
compressor
5°C °C/°F ---
Delay High discharge temperature alarm activation delay for the integrated parallel compressor 5 s ---
Cca13 DO relay line DO position and display status (ON/OFF) for integrated parallel compressor --- --- DO1…DO18
Logic DO logic of integrated parallel compressor power supply NC --- NC | NO
Cca14 AO Integrated parallel compressor modulating device AO position --- --- 01…06
Status (display only) Integrated parallel compressor modulating device AO value 0.0 % 0…100.0
Tab. 7.d
Mask index Display description Description Def. U. of M.Values
D.Condensers
The I/Os depend on the con guration selected, the following are only examples. See Appendix A.1 for the complete list and position of available I/Os.
Daa01 DI Fan 1 overload DI position (line 1) … --- ---, 01…18,
U1…U10 (****)
Status (display only) Fan 1 overload DI status (line 1) --- --- closed | open
Logic Fan 1 overload DI logic (line 1) NC --- NC | NO
Function (display only) Fan 1 overload function status (line 1) --- --- not active | active
…… … ………
