pRack PR300T +0300018EN rel. 1.5 - 02.05.2017
Mask index Display description Description Def. U. of M.Values
Ib75 S1 Enable stages and stages for compressor group 1 (line 1) YES
100
---
%
NO | YES
100 | 50/100 |
50/75/100 |
25/50/75/100 |
33/66/100
…… ………
S46 Enable stages and stages for compressor group 4 (line 1) NO
---
---
kW
NO | YES
S1…S4
Ib76 C01 Size for compressor 1 or presence of inverter (line 1) S1 --- S1…S4 | INV
…… ………
C12 Size for compressor 6 (line 1) S1 --- S1…S4
Ib60 Compress. size Compressors sizes (line 1) Same size --- Same size | De ne
sizes
Ib61 S1 Enable size and size for compressor group 1 (line 1) YES'
---
---
kW
NO | YES
0.0…500.0
…… ………
S4 Enable size and size for compressor group 4 (line 1) NO
---
---
kW
NO | YES
0.0…500.0
Ib62 C01 Size for compressor 1 or presence of inverter (line 1) S1 --- S1…S4 | INV
…… ………
C12 Size for compressor 6 (line 1) S1 --- S1…S4
Ib80 Regulation Compressor control by temperature or pressure (line 1) Pressure --- Pressure
Temperature
Units of measure Units of measure (line 1) barg --- …
Refrigerant Type of refrigerant (suction line 1) R744 --- R22 | R134a
R404A | R407C
R410A | R507A
R290 | R600 R600a
| R717
R744 | R728
R1270 | R417A
R422D | R413A
R422A | R423A
R407A | R427A
R245Fa | R407F | R32
Ib81 Regulation type Compressor regulation type (line 1) Dead zone --- Proportion. band
Dead zone
Enable integral time action Enable integral time for proportional regulation of suction line (line 2) NO --- NO | YES
Ib82 Setpoint Setpoint without compensation (suction line 2) 3,5 barg …(**) …(**)
Di erential Di erential (suction line 2) 0,3 barg …(**) …(**)
Ib90 Dedicated pRack board for
cond. line
Suction and condensing lines on di erent boards, that is condensing line on dedicated
board
NO --- NO | YES
Ib91 Number of fans Number of fans (line 1) 3 --- 0…16
Ib54 Modulate speed device Fan modulating device (line 1) None --- None | Inverter
Contr. taglio di fase
Ib93 Regulation Fan regulation by pressure or temperature (line 1) Pressure --- Pressure |
Temperature
Units of measure Units of measure (line 1) barg --- …
Refrigerant Type of refrigerant (condensing line 1) R744 --- R22 | R134a
R404A | R407C
R410A | R507A
R290 | R600
R600a | R717
R744 | R728
R1270 | R417A
R422D | R413A
R422A | R423A
R407A | R427A
R245Fa | R407F | R32
Ib94 Regulation type Fan regulation type (line 1) Banda
proporz.
--- Banda proporz. |
Dead zone
Enable integral time action Enable integral time for proportional regulation NO --- NO | YES
Ib95 Setpoint Setpoint without compensation (condens. line 1) 12.0 barg …(**) …(**)
Di erential Di erential (condensing line 1) 2.0 barg …(**) …(**)
Ib96 Con gure another condens.
line
Con guration of a second condensing line NO --- NO | YES
Ib1a Number of fans Number of fans (line 2) 3 --- 0…16
…… …
………
I
b1e Di er
ential Di erential (condensing line 2) 2.0 barg …(**) …(**)
Ic01 Type of system Type of system Aspiraz. +
Conden.
--- Suction Condenser
Aspiraz. + Conden.
Ic02 Units of measure Unit of measure °C/barg --- °C/barg | °F/psig
Ic03 Number of suction lines Number of suction lines 1 --- 0…2
Ic04 Dedicated pRack board for
suction line
Suction line in separate boards NO --- NO | YES
Ic05 Compressor type Type of compressors (line 1) Recriproc. --- Recriprocating |
Scroll
Number of compressors Number of compressors (line 1) 4 --- 1…6/12 (*)
Ic06 Compressor type Type of compressors (line 2) Recriproc. --- Recriprocating |
Scroll
Number of compressors Number of compressors (line 2) 0 --- 1…6
Ic07 Condenser line number System condensing line number 1 --- 0…2
Ic08 Line 1 Number of fans (line 1) 4 --- 0…16
Line 2 Number of fans (line 2) 0 --- 0…16
Ic09 Dedicated pRack board for
cond. line
Condensing lines in separate boards NO --- NO | YES
Ic10 (solo visual.) Boards needed pLAN boards needed for the selected con guration --- --- ---
Id01 Save con guration Save Manufacturer con guration NO --- NO | YES
Load con guration Install Manufacturer con guration NO --- NO | YES
Id02 Reset Carel default Install default Carel con guration NO --- NO | YES
Tab. 7.j
(*) According to compressor type
(**) According to unit of measure selected
(***) According to compressor manufacturer, refer to the related paragraph.
(****) According to hardware size
Page 130 of 177
Copyright HPL January 2021
P4115S Rev 02
